# EKF localization with known correspondences

Been a while since I posted anything. I recently found some free time and decided to dust off the Probabilistic Robotics book by Thrun et. al. There are a lot of topics in the book that I didn’t learn formally back during school.

I’ve used the vanilla Kalman Filter for a few projects in the past but not the extended Kalman Filter. I decided to implement the Extended Kalman Filter localization with known correspondences algorithm. The simulation consists of a robot with a range sensor that can detect known landmarks in the world. You move the robot around using the arrow keys. The simulation is written in C++ and uses SDL and OpenGL. Below shows a screenshot. The true pose is in green, gray the EKF estimate and 95% confidence ellipse, red are the landmarks.

One addition I made was handle the case when angular velocity is zero. The original algorithm presented in the book would result in a divide by zero. You can grab and play with the code here.

An interesting behavior that I’ve been trying to understand is the EKF covariance can shrink (reduce uncertainty), even if you are only doing predictions (no correction using landmark). It’s either a coding bug or some side effect of linearization. Either way, it’s driving me nuts!

https://github.com/nghiaho12/EKF_localization_known_correspondences

# Using TensorFlow/Keras with CSV files

I’ve recently started learning TensorFlow in the hope of speeding up my existing machine learning tasks by taking advantage of the GPU. At first glance the documentation looks decent but the more I read the more I found myself scratching my head on how to do even the most basic task. All I wanted to do was load in a CSV file and run it through a simple neural network. When I was downloading the necessary CUDA libraries from NVIDIA I noticed they listed a handful of machine learning framework that were supported. One of them was Keras, which happens to build on top of TensorFlow. After some hard battles with installing CUDA, TensorFlow and Keras on my Ubuntu 16.04 box and a few hours of Stackoverflow reading I finally got it working with the following python code.

from keras.models import Sequential
from keras.layers import Dense, Activation

import numpy as np
import os.path

if not os.path.isfile("data/pos.npy"):
np.save('data/pos.npy', pos);
else:

if not os.path.isfile("data/neg.npy"):
np.save('data/neg.npy', neg);
else:

pos_labels = np.ones((pos.shape[0], 1), dtype=int);
neg_labels = np.zeros((neg.shape[0], 1), dtype=int);

print "positive samples: ", pos.shape[0]
print "negative samples: ", neg.shape[0]

HIDDEN_LAYERS = 4

model = Sequential()

model.compile(optimizer='rmsprop', loss='binary_crossentropy', metrics=['accuracy'])
model.fit(np.vstack((pos, neg)), np.vstack((pos_labels, neg_labels)), nb_epoch=10, batch_size=128)

# true positive rate
tp = np.sum(model.predict_classes(pos))
tp_rate = float(tp)/pos.shape[0]

# false positive rate
fp = np.sum(model.predict_classes(neg))
fp_rate = float(fp)/neg.shape[0]

print ""
print ""

print "tp rate: ", tp_rate
print "fp rate: ", fp_rate



I happened to have my positive and negative samples in separate CSV files. The CSV files are converted to native Numpy binary for subsequent loading because it is much faster than parsing CSV. There’s probably some memory wastage going on with the np.vstack that could be improved on.

# Understanding OpenCV cv::estimateRigidTransform

OpenCV’s estimateRigidTransform is a pretty neat function with many uses. The function definition is

Mat estimateRigidTransform(InputArray src, InputArray dst, bool fullAffine)

The third parameter, fullAffine, is quite interesting. It allows the user to choose between a full affine transform, which has 6 degrees of freedom (rotation, translation, scaling, shearing) or a partial affine (rotation, translation, uniform scaling), which has 4 degrees of freedom. I’ve only ever used the full affine in the past but the second option comes in handy when you don’t need/want the extra degrees of freedom.

Anyone who has ever dug deep into OpenCV’s code to figure out how an algorithm works may notice the following:

• Code documentation for the algorithms is pretty much non-existent.
• The algorithm was probably written by some soviet Russian theoretical physicists who thought it was good coding practice to write cryptic code that only a maths major can understand.

The above applies to the cv::estimateRigidTransform to some degree. That function ends up calling static cv::getRTMatrix() in lkpyramid.cpp (what the heck?), where the maths is done.

In this post  I’ll look at the maths behind the function and hopefully shed some light on how it works.

# Full 2D affine transform

The general 2D affine transform has 6 degree of freedoms of the form:

$T = \left[ \begin{array}{ccc} a & b & c \\ d & e & f \end{array} \right]$

This transform combines rotation, scaling, shearing, translation and reflection in some cases.

Solving for T requires a minimum of 3 pairing points (that aren’t degenerate!). This is straight forward to do. Let’s denote the input point to be X= [x y 1] and the output to be Y = [x’ y’ 1], giving:

$TX = Y$

$\left[ \begin{array}{ccc} a & b & c \\ d & e & f \end{array} \right] \left[\begin{array}{c} x \\ y \\ 1\end{array}\right] = \left[\begin{array}{c} x' \\ y' \\ 1\end{array}\right]$

Expanding this gives

$\begin{array}{c} {ax + by + c = x'} \\ {dx + ey + f = y'}\end{array}$

We can re-write this as a typical Ax = b matrix and solve for x. We’ll also need to introduce 2 extra pair of points to be able to solve for x.

$\left[\begin{array}{cccccc} x_1 & y_1 & 1 & 0 & 0 & 0 \\ 0 & 0 & 0 &x_1 & y_1 & 1 \\ x_2 & y_2 & 1 & 0 & 0 & 0 \\ 0 & 0 & 0 &x_2 & y_2 & 1 \\ x_3 & y_3 & 1 & 0 & 0 & 0 \\ 0 & 0 & 0 &x_3 & y_3 & 1\end{array}\right]\left[\begin{array}{c} a \\ b \\ c \\ d \\ e \\ f \end{array} \right] = \left[\begin{array}{c} x_1 \\ y_1 \\ x_2 \\ y_2 \\ x_3 \\ y_3 \end{array} \right]$

Now plug in your favourite linear solver to solve for [a, b, c, d, e, f].

If you have more than 3 pair of points then you can do least squares by doing:

$\begin{array}{ccc} Ax & = & b \\ A{^T}Ax & = & A^{T}b \\x & =& (A{^T}A)^{-1}A{^T}b \end{array}$

# Partial 2D affine transform

The partial affine transform mentioned early has a reduced degree of freedom of 4 by excluding shearing leaving only rotation, uniform scaling and translation. How do we do this? We start with the matrices for the transforms we are interested in.

$R (rotation) = \left[\begin{array}{cc} \cos(\theta) & -\sin(\theta) \\ \sin(\theta) & \cos(\theta)\end{array}\right]$

$S (scaling) = \left[\begin{array}{cc} s & 0 \\ 0 & s \end{array}\right]$

$t (translation) = \left[\begin{array}{c} tx \\ ty \end{array}\right]$

Our partial affine transform is

$T = \left[RS | t \right]$

Expanding gives

$T = \left[ \begin{array}{ccc} \cos(\theta)s & -\sin(\theta)s & tx \\ \sin(\theta)s & \cos(\theta)s & ty\end{array} \right]$

We can rewrite this matrix by defining

$a = \cos(\theta)s$

$b = \sin(\theta)s$

$c = tx$

$d = ty$

$T = \left[ \begin{array}{ccc} a & -b & c \\ b & a & d\end{array} \right]$

Solving for [a, b, c, d]

$TX = Y$

$\left[ \begin{array}{ccc} a & -b & c \\ b & a & d \end{array} \right] \left[\begin{array}{c} x \\ y \\ 1\end{array}\right] = \left[\begin{array}{c} x' \\ y' \\ 1\end{array}\right]$

$\begin{array}{c} {ax- by + c = x'} \\ {bx + ay + d = y'}\end{array}$

Solving for [a, b, c, d]

$\left[\begin{array}{cccc} x_1 & -y_1 & 1 & 0 \\ y_1 & x_1 & 0 & 1 \\ x_2 & -y_2 & 1 & 0 \\ y_2 & x_2 & 0 & 1 \end{array}\right]\left[\begin{array}{c} a \\ b \\ c \\ d \end{array} \right] = \left[\begin{array}{c} x_1 \\ y_1 \\ x_2 \\ y_2 \end{array} \right]$

Notice for the partial affine transform we only need 2 pair of points instead of 3.

# Final remark

Well, that’s it folks. Hopefully that gives you a better understanding of the 2D affine transform. So when should you use one or the other? I tend to the use the partial affine when I don’t want to overfit because the data has some physical constraint. On the plus side, it’s a bit faster since there are less parameters to solve for. Let me know which one you use for your application! Best answer gets a free copy of OpenCV 3.x 🙂

# Computer vision on the FPGA

This is a follow up on my previous post about my first step into the FPGA world. In this post I’ll give a high level description of my implementation of a simple 3×3 convolution image filtering circuit. It does not aim to be fast or efficient, just something that works. If you want to know anything in more detail look at the code or leave a comment below.

I’ll assume the reader is familiar with 3×3 filters like the Sobel edge detector. In this project l implement the Laplacian filter, but you can easily change the filter by changing the hard coded values inside the Verilog file.

Below is a high level overview of my FPGA design. I’ve omitted the input/output pins for each of the block component for simplicity.

The laptop sends the image over the serial one row at a time to the FPGA. The FPGA then immediately sends the processed pixel row back to the laptop. I chose this design because it only requires three row buffers on the FPGA. The Basys2  has 72Kbits of fast RAM.  For an image width of 128 pixels, it only requires 128×3 = 384 bytes of RAM.

The state machine handles all the logic between the serial, BRAM and 3×3 linear filter.

I decided to use serial for communication between the laptop and FPGA because it was simpler, though slower. I did however manage to crank up the serial speed to 1.5 Mbit by adding an external 100Mhz crystal oscillator. Using the default 50Mhz oscillator on the Basys2 I can get up to 1 Mbit.

I use three banks of dual port BRAM (block RAM). The dual port configuration allows two simultaneously read/write to the same BRAM. This allows me to read 3×2=6 pixels  in one clock cycle. For 3×3=9 pixels it takes two clock cycles. I could do better by making the read operation return more pixels. The three banks of BRAM act as a circular buffer. There’s some logic in the state machine that keeps track of which bank of BRAM to use for a given input pixel row.

Right now with the my current BRAM configuration and 3×3 filter implementation it takes 5 clock cycles to process a single pixel, excluding serial reading/writing. If you include the serial transmission overhead then it takes about 380 ms on my laptop to process a 128×128 grey image.

Below is the result of the Laplacian filter on Lena. I ignored the pixels on the border of the image, so the final image is 126×126.

FPGA_3x3_filter.zip

The zip file contains only the necessary Verilog code and a main.cpp for sending the image. The main.cpp requires OpenCV for display. I omitted any Xilinx ISE specific project files to keep it simple. But if there’s any missing files let me know. Your input image must be 128×128 in size to work.
